C1300FDi
C1300FDI
DSP DRIVE FOR THE INSTALL.
A 2 x 650 W install amplifier with onboard FIR drive, built to tune a fixed system and forget it.
Set the system once and let it hold. The C1300FDi pairs a 2 x 650 W Class-AB output stage with full FIR-capable DSP — output delay, a 31-band graphic EQ and PEQ per channel, and load-impedance monitoring — so a permanent install is dialed in tight from day one. Direct-drive 70 V/100 V operation feeds distributed lines without a transformer, and Phoenix connectors keep the wiring clean. Retail, hospitality, house of worship — the processing lives in the box, and the room just sounds right.
Key features
Tune it precisely
FIR filters, 31-band GEQ, and PEQ per channel onboard.
Drive distributed lines
direct-drive 70 V/100 V output, no transformer needed.
Protect the system
load-impedance monitoring plus full audio and thermal limiters.
Wire it clean
Phoenix connectors and a 19-inch, 2 RU install chassis.
Set and selectable
remote power and preset-select inputs for fixed installs.
Runs cool
front-to-rear three-stage fans, rated for +5°C to +40°C ambient.
Two-channel power amplifiers
L Series and C Series Amplifiers
Complete the System
Where this unit fits, and what it pairs with.
Specifications
Overview & Features
- Configuration
2-channel
Acoustic Performance
- Frequency Response
10 Hz to 21 kHz (±1 dB)
- THD+N
< 0.05 %
- Crosstalk between channels (dBA)
< -80 dB
- Signal-to-Noise Ratio
>104 dB
Power & Amplification
- Total Output Power*
1300 W
