EKX 12P
Plug In. Dial It. Go.
Maximum impact, minimum effort, and will stay cool under pressure. EKX family is ready for the gig the moment you set it down.
Set it on a pole and you are ready to play. The EKX 12P drives an EV-engineered EVS-12M woofer and a DH-1M 1-inch titanium compression driver with a 1,500 W Class-D amp, for up to 132 dB SPL. Onboard QuickSmartDSP gives you presets, system-match crossovers, and limiting from the rear panel, and intelligent thermal management keeps it steady through a long night. Mobile DJ, band, house of worship, install: the show goes wherever you do.
Key Features
Big, Clean Output
up to 132 dB SPL from a 1,500 W Class-D amplifier.
Tune It on the Spot
integrated QuickSmartDSP presets, crossovers, and limiting on the rear panel.
EV-Engineered Sound
EVS-12M woofer paired with a DH-1M 1-inch titanium compression driver.
Runs Cool, Runs Long
intelligent thermal management with a variable-speed fan.
Controlled Coverage
patented SST waveguide keeps the pattern tight and the sound honest.
Pole It and Play
set it on a pole and you are ready to play.
Specifications
Acoustic Performance
- Max SPL
132
- Frequency Response
60 Hz - 18 kHz
- Frequency Range (-10 dB)
50 Hz - 20 kHz
- Coverage Angle
90 × 60
Transducers & Drivers
- LF transducer size (in)
DH-1M 1 in titanium compression driver
- Woofer Size
EVS-12M 300 mm (12 in)
