L1800FD
Step up the output, keep the processing on board. The L1800FD delivers 2 x 950 W with a Class-AB output stage, FIR-Drive linear-phase tuning, and XLR/NL4 connectors. Per-channel EQ, delay, and limiters shape the system, and a full protection set — thermal, DC, HF, Back-EMF, and short-circuit — keeps it honest. A 32 dB voltage gain and >105 dB signal-to-noise hold the noise floor down. Touring rig, club, worship, performing-arts space.
Key features
More headroom per channel
2 x 950 W with a low noise floor (>105 dB signal-to-noise).
Loudspeaker tuning on board
FIR-Drive linear-phase processing with per-channel EQ, delay, and limiters.
Wire it fast
balanced XLR inputs and NL4 outputs for quick, reliable hookup.
Built to keep running
protection against thermal, DC, HF, Back-EMF, and short-circuit faults.
Stays cool under load
front-to-rear, three-stage fan cooling for tight racks.
Matched to local mains
ships factory configured for 240 V, 230 V, 120 V or 100 V mains, 50 to 60 Hz.
Two-channel power amplifiers
L Series and C Series Amplifiers
Complete the System
Where this unit fits, and what it pairs with.
Specifications
Overview & Features
- Configuration
2-channel, Class AB
Acoustic Performance
- Frequency Response
10 Hz to 21 kHz (±1 dB)
- THD+N
< 0.05 %
- Crosstalk between channels (dBA)
< -80 dB
- Signal-to-Noise Ratio
>105 dB
Power & Amplification
- Total Output Power*
1800 W
