RE92H
Same disappearing act, finished for a white ceiling. The RE92HW is a miniature cardioid electret condenser made to suspend above the source (choir, stage, or theater) with high gain before feedback and a clear, natural voice. At 10.5 mm across in non-reflecting white, it stays out of sight against pale surfaces. The integrated wire director bends to aim the capsule, and the 25-foot cable lands on screw terminals at the inline module, so trimming it is simple.
Key features
Catch distant sources clean
Uniform cardioid pattern and high sensitivity built for overhead pickup.
Vanish against light ceilings
Non-reflecting white finish on a 10.5 mm capsule.
Point it exactly
Integrated wire director bends to aim the capsule at the source.
Cut the cable to fit
25-foot lead lands on screw terminals at the inline module for easy shortening.
Hold gain in a loud room
Cardioid pattern keeps feedback down with a clear condenser voice.
Runs on standard phantom
Any 24-to-52-volt phantom supply powers it through the inline module.
Specifications
Acoustic Performance
- Max SPL
135
- Frequency Response
40 Hz to 20,000 Hz
- Polar Pattern
Cardioid
- Signal-to-Noise Ratio
>105 dB
Transducers & Drivers
- Element Type
Self-Biased condenser, back electret
Impedance
- Nominal Impedance
250 ohms
